CURTAIN WALL
Our range of curtain walls is designed to offer efficient insulation and a great deal of design freedom. Designed to integrate harmoniously into any type of architecture, our facade systems combine perfectly with our skylight systems. Their large load-bearing capacity makes it possible to cover large openings up to 3m in width and 5m in height, without bulky frames, ideal for ambitious architectural projects.
Composition
Notre système de mur-rideaux est une solution de construction modulaire en acier conçue pour des performances thermiques exceptionnelles, avec un certificat Passivhaus. Ses composants sont adaptables pour répondre aux exigences structurelles et aux besoins de chaque projet, qu'il s'agisse de nouvelles constructions ou de rénovations.
Technical data
Material options
Our curtain wall profiles are available in stainless steel for a natural or burnished finish, in corten steel for an assumed patina and in galvanized steel for a uniform baked paint coating.
Breakage of the thermal bridge
Polyurethane composite structure - polyamide thermal bridge
Our facade system offers good thermal performance, with U values of up to 0.65 W/m²·K. It is designed with elegant and very thin steel profiles (profile face widths of 50 or 60 mm) that can accommodate glazing from 16 mm to 70 mm thick.
Its high-strength steel structure integrates a thermal bridge break composed of profiles separated by insulating bars made of polyamide reinforced with glass fibers. This device limits heat transfers between the outside and the inside, considerably improving thermal insulation and energy performance. Combined with high-performance insulating glass, the system guarantees maximum luminosity, long-lasting tightness and exceptional durability, while maintaining fine and elegant lines adapted to all architectural styles.
Type of openings
Finishing
An elegant and discreet complement, Secco Sistemi handles harmonize with the clean lines of the windows, adapted to the profile with subtle variations.
