SKYLIGHT
Our range of skylights is a high-end solution for glass roofs and skylights. Thanks to its high-strength steel structure and its profiles with thermal break, the system allows the production of glazed surfaces that allow a degree of inclination between 7 and 80 degrees. Designed to integrate harmoniously into any type of architecture, our skylight system combines perfectly with our vertical facade systems. Their large load-bearing capacity makes it possible to cover large openings without cumbersome frames, ideal for ambitious architectural projects.
Composition
Notre système de puits de lumière est une solution modulaire en acier conçue pour offrir une isolation thermique optimale, certifiée Passivhaus. Ses profilés et composants sont flexibles et peuvent être adaptés à chaque projet, que ce soit pour de nouvelles constructions ou des rénovations, tout en permettant l’intégration de vitrages de différentes épaisseurs pour répondre aux besoins architecturaux et énergétiques spécifiques.
Technical data
Material options
The skylight system is available in stainless steel for a natural or burnished finish, in corten steel for an assumed patina and in galvanized steel for a uniform baked paint coating. Steel is a durable and recyclable material that is designed to last for decades with minimal maintenance.
Breakage of the thermal bridge
Thermal performance
Our skylight system offers good thermal performance, with U values of up to 0.64 W/m²·K. It is designed with elegant and very fine steel profiles (profile face widths of 50 or 60 mm) that can accommodate glazing from 16 mm to 70 mm thick.
Its high-strength steel structure integrates a thermal bridge break composed of profiles separated by insulating bars made of polyamide reinforced with glass fibers. This device limits heat transfers between the outside and the inside, considerably improving thermal insulation and energy performance. Combined with high-performance insulating glass, the system guarantees maximum luminosity, long-lasting tightness and exceptional durability, while maintaining fine and elegant lines adapted to all architectural styles.
Type of openings
Finishing
An elegant and discreet complement, Secco Sistemi handles harmonize with the clean lines of the windows, adapted to the profile with subtle variations.
