DOORS AND WINDOWS

Door and window systems are designed to meet Canadian climate requirements in addition to offering unparalleled aesthetics. Thanks to the profile depth of 75 mm, the W75 TB makes it possible to integrate highly efficient insulating glass (double or triple glazing), up to 52 mm thick, to optimize energy efficiency. Ferhōm doors and windows combine ultra-fine and aesthetic lines with high thermal and acoustic performance, while guaranteeing the durability and reliability of demanding architectural structures.

Composition

Ferhōm doors and windows consist of 75mm or 83mm deep steel posts and crosspieces, connected by a thermal bridge break made of polyamide reinforced with glass fibers. This design makes it possible to integrate high-performance insulating glass, double or triple, up to 57 mm thick. Steel, available in galvanized, corten or stainless steel, ensures exceptional rigidity and ultra-thin profile lines, maximizing the glazed area and the supply of natural light, while offering durability, high level thermal and acoustic insulation.

Technical data

Largeur apparente du vantail	27mm
Surface maximale du vantail opérable	jusqu'à 38.67pi2
Surface maximale fixe	Limité par fabricant de verre
Épaisseur du vitrage	32 à 57mm
Coefficient de transmission thermique	Uw ≥ jusqu'à 0.6 W/m²K (selon vitrage)
Niveau de performance	Classe CW
Essai d'étanchéité à l'air	infiltration/exfiltration ASTM E283
Essai pénétration d'eau	ASTM E331 & ASTM E547
Essai performance structurale	ASTM E330
Essais selon NAFS 17&22 avec supplément canadien	complété

Material options

Our door and window profiles are available in stainless steel for a natural or burnished finish, in corten steel for an assumed patina and in galvanized steel for a uniform baked paint coating and in widely diversified colors.

Galvanized Steel

AISI 304 or 316L Stainless Steel

Corten Steel

Breakage of the thermal bridge

Thermal bridge break with reinforced polyamide

To meet Canadian climate requirements, the thermal barrier is provided by a polyamide insulation reinforced with glass fibers, offering excellent thermal performance. This material is at the same time robust, lightweight and highly insulating, significantly reducing heat transfer between the inside and the outside.

The thermal insulation obtained in this way allows the system to reach U values compatible with the requirements of Passive House Canada buildings. The system is also equipped with double EPDM seals, ensuring excellent resistance to water and wind.
